halcon 0.0.1

Python implementation of FALCON: Feedback Adaptive Loop for Content-Based Retrieval

halcon

halcon (falcon in Spanish) is a python implementation of the Feedback Adaptive Loop for Content-Based Retrieval (FALCON) algorithm as described in

  • Leejay Wu, Christos Faloutsos, Katia P. Sycara, and Terry R. Payne. 2000. FALCON: Feedback Adaptive Loop for Content-Based Retrieval. In Proceedings of the 26th International Conference on Very Large Data Bases (VLDB ‘00), Amr El Abbadi, Michael L. Brodie, Sharma Chakravarthy, Umeshwar Dayal, Nabil Kamel, Gunter Schlageter, and Kyu-Young Whang (Eds.). Morgan Kaufmann Publishers Inc., San Francisco, CA, USA, 297-306.

FALCON is, as described in the article abstract, “a novel method that is designed to handle disjunctive queries within metric spaces. The user provides weights for positive examples; our system ‘learns’ the implied concept and returns similar objects.”

Master branch status

Pre-Requisites

  • numpy
  • scipy

To install the prerequisites in Ubuntu 12.04

sudo apt-get install update
sudo apt-get install python-numpy python-scipy

Installation

There are several ways to install halcon. The most common way is to download the source code, unzip/untar the source code package and run the command

sudo python setup.py install

I have plans of submitting this package to the Python Package Index. If I do so, then should be able to install it by running the command

sudo pip install halcon

COMMENT: halcon depends on numpy and scipy. Installing these packages in Windows and MacOSX is not a trivial task. For more information refer to the documentation.

If you wish to install halcon in a virtual enviroment, then you can do

virtualenv halcon
cd halcon
source ./bin/activate
pip install numpy
pip install scipy
mkdir src
cd src
git clone git@github.com:icaoberg/halcon.git
cd halcon
python setup.py install
cd ../../
deactivate

COMMENT: The previous snippet assumes that you have virtualenv installed in your working system.

Usage

There is only one method that you need to know about

halcon.search.query(good_set, candidates, alpha=-5,
        metric='euclidean', normalization='zscore', debug=False)

Here is a brief description of each of the input arguments

  • good_set and candidates are two lists of lists where each member of both lists has the same shape.

record = [<identifier>, <initial_score>, <feature_vector>]

For example in wine.py, I download a CSV file where the first feature_vector looks like this

[1,14.23,1.71,2.43,15.6,127,2.8,3.06,.28,2.29,5.64,1.04,3.92,1065]

and then I modify it like this

good_set = []
identifier = 'wine00'
initial_score = 1
feature_vector = [1,14.23,1.71,2.43,15.6,127,2.8,3.06,.28,2.29,5.64,1.04,3.92,1065]
good_set.append([identifier, initial_score, feature_vector])

For more information about the definition of the initial score, please refer to the article. In all my examples I use a initial score of 1, that is, all images have the same weight. The identifier should be unique (though not enforced), so you can tell images apart. This package assumes every object is represented by a feature vector. Feature calculation goes beyond the scope of this package. There are many feature calculation/machine learning packages out there that you might find useful, like OpenCV, mahotas and SLIC.

  • alpha. For more information about alpha, please refer to the article. The recommended value by the paper is -5, which is the default value used in this package.
  • metric. In the research article, a measure of distance d is used to calculate the distance between two feature vectors. The default value is euclidean (Euclidean distance) and other supported metrics are cityblock (Manhattan distance) and hamming (Hamming distance).
  • normalization. Feature normalization option. Default is zscore. Alternative option is standard.
  • debug. If debug flag is on, then it should print more information about the calculation as they happen.

Examples

For convenience and testing I included some examples. These examples download some datasets from the web and use them to trigger a query. The only exception is the random feature vectors example. For example, to run the iris example simply run in terminal

python examples/iris.py

The examples have a dependency that the package does not, since I use tabulate to pretty print the results from the examples.

In my humble opinion, the best way to run the examples is using virtualenv -which is what I do for travis-. The next commands assume you have virtualenv available.

virtualenv halcon --system-site-packages
. ./halcon/bin/activate
cd halcon
mkdir src
cd src
pip install numpy
pip install scipy
pip install tabulate
git clone https://github.com/icaoberg/halcon.git
cd halcon
python setup.py install
cd ..
python examples/iris.py

iris.py

$ python examples/iris.py
This example uses the iris dataset from
Machine Learning Repository
Center for Machine Learning and Intelligent Systems
http://archive.ics.uci.edu/ml/datasets/Iris
I will use the first feature vector as my query image
[[0, 1, array([ 5.1,  3.5,  1.4,  0.2,  1. ])]]
And I will use the rest of the feature vectors to find the most similar images
Now notice that feature vector with iid1 has the same values iid0
[1, 1, array([ 5.1,  3.5,  1.4,  0.2,  1. ])]
So I expect that if halcon is working correctly, then iid1 should be the top hit!
Elapsed time: 0.0221660137177 seconds

  Ranking    Identifier  Class                  Score
---------  ------------  ---------------  -----------
        0             1  Iris-setosa      0
        1            28  Iris-setosa      1.27788e-43
        2             5  Iris-setosa      2.40121e-40
        3            29  Iris-setosa      2.40121e-40
        4            40  Iris-setosa      5.83391e-40
        5             8  Iris-setosa      7.04398e-39
        6            18  Iris-setosa      1.1259e-35
        7            41  Iris-setosa      1.51906e-34
        8            50  Iris-versicolor  6.99696e-34
        9            37  Iris-setosa      1.09221e-32
       10            12  Iris-setosa      1.22203e-32
       11            49  Iris-setosa      2.05046e-32
       12            11  Iris-setosa      4.25801e-31
       13            21  Iris-setosa      6.55842e-31
       14            47  Iris-setosa      5.54098e-29
       15            36  Iris-setosa      7.93943e-29
       16             7  Iris-setosa      2.16985e-28
       17            20  Iris-setosa      4.23544e-28
       18            25  Iris-setosa      1.67453e-27
       19             3  Iris-setosa      2.40919e-27

Do the top results in the list above belong to the same class as the query image?
If so, then SCORE! It seems to work.

wine.py

$ python examples/wine.py
This example uses the wine dataset from
Machine Learning Repository
Center for Machine Learning and Intelligent Systems
http://archive.ics.uci.edu/ml/datasets/Wine
I will use the first three feature vectors as my query wine set
And I will use the rest of the feature vectors to find the most similar images
Elapsed time: 0.0280928611755 seconds

  Ranking  Identifier          Score
---------  ------------  -----------
        0  wine1         0
        1  wine2         0
        2  wine3         0
        3  wine21        2.77663e-05
        4  wine30        0.000629879
        5  wine23        0.00252617
        6  wine49        0.00318536
        7  wine57        0.00456123
        8  wine36        0.0152067
        9  wine39        0.0197516
       10  wine58        0.0243848
       11  wine9         0.024467
       12  wine55        0.045762
       13  wine24        0.046893
       14  wine7         0.113906
       15  wine45        0.188355
       16  wine27        0.201802
       17  wine41        0.206469
       18  wine31        0.288536
       19  wine56        0.291853

metrics.py

$ python examples/metrics.py
This example uses the wine dataset from
Machine Learning Repository
Center for Machine Learning and Intelligent Systems
http://archive.ics.uci.edu/ml/datasets/Wine
This example uses this dataset to compare the different metrics available in halcon

  Ranking  Euclidean    City Block    Hamming
---------  -----------  ------------  ---------
        0  wine1        wine1         wine1
        1  wine21       wine21        wine5
        2  wine57       wine57        wine47
        3  wine41       wine23        wine3
        4  wine23       wine30        wine9
        5  wine30       wine41        wine17
        6  wine45       wine49        wine25
        7  wine10       wine55        wine30
        8  wine48       wine9         wine36
        9  wine7        wine7         wine39
       10  wine36       wine36        wine41
       11  wine55       wine10        wine45
       12  wine56       wine45        wine52
       13  wine52       wine56        wine2
       14  wine3        wine48        wine4
       15  wine43       wine47        wine6
       16  wine9        wine52        wine7
       17  wine49       wine3         wine8
       18  wine29       wine17        wine10
       19  wine8        wine8         wine11

COMMENT: Hamming distance is meant for comparing strings so this example does not make a lot of sense since these features do not represent characters.

random_feature_vectors.py

$ python examples/random_feature_vectors.py
Generating random query image
Query image name: img
Elapsed time: 7.39097595215e-05 seconds
Generating random dataset
Elapsed time: 0.00141191482544 seconds
Querying with one image
Elapsed time: 0.0233750343323 seconds
Top Ten Results!
  Ranking  Identifier          Score
---------  ------------  -----------
        0  img           0
        1  8             1.30582e+14
        2  85            2.70987e+14
        3  25            3.68567e+14
        4  97            6.19091e+14
        5  11            6.54178e+14
        6  70            6.55048e+14
        7  91            6.89901e+14
        8  79            7.17429e+14

number_of_feature_vectors_performance-euclidean_distance.py

$ python examples/number_of_feature_vectors_performance-euclidean_distance.py
Generating and querying on synthetic datasets, please wait...

These are the results from this test
  Number of Feature Vectors    Time (in seconds)
---------------------------  -------------------
                        100            0.0247221
                        200            0.0378191
                        300            0.0665781
                        400            0.0999439
                        500            0.123964
                        600            0.120883
                        700            0.138576
                        800            0.176096
                        900            0.180116

There is a clear trend that is dependent on the number of feature vectors.
You know what? Why don't we try making a pretty plot as well

COMMENT: the examples are not seeded so you might get different results.

number_of_features_performance-euclidean_distance.py

$ python examples/number_of_features_performance-euclidean_distance.py
Generating and querying on synthetic datasets, please wait...                   ]

These are the results from this test

  Number of Features    Time (in seconds)
--------------------  -------------------
                  50            0.0666399
                 100            0.0619891
                 150            0.0683651
                 200            0.0779331
                 250            0.077204
                 300            0.0829229
                 350            0.087312
                 400            0.092144
                 450            0.09745
                 500            0.111081
                 550            0.112051
                 600            0.11652
                 650            0.119202
                 700            0.123624
                 750            0.127126
                 800            0.134157
                 850            0.138586
                 900            0.149411
                 950            0.14823

There is a clear trend that is dependent on the number of feature vectors.
You know what? Why don't we try making a pretty plot as well

COMMENT: the examples are not seeded so you might get different results.

Documentation

Documentation was written using Sphinx. To generate documentation use the following commands.

To generate html

cd docs
make html

To generate PDF document

cd docs
make latexpdf

To generate epub document

cd docs
make epub

Bugs and Questions

To submit bugs about the source code visit

https://github.com/icaoberg/falcon

To submit bugs about the documentation visit

https://github.com/icaoberg/falcon-docs

For any other inquiries visit those links as well.
